Toroidal transformer 200VA 2x115V 2x9V 18V Lumonic RSO-825037

Available, delivery time: 1-3 days

Article-No.: IT-001447

Model: RSO-825037

Shipping weight: 2.3 kg

Shipping Zone: 80

ROHS: Ja

Datasheet:

Quantity	Unit price
1 - 2	€60.00
3 - 5	€59.40
6 - 10	€58.80
11 - 20	€58.20
21 - 50	€57.60
From 51	€57.00

Content: 1 Stück

Stk

detail.currentStock

Product description

✔ Mark of conformity: EN61558-2 / VDE 0570 with ENEC and UL

✔ Galvanically separated primary and secondary winding (isolating transformer!)

✔ Very low stray magnetic field

✔ Very low no-load losses

✔ Very high efficiency

✔ Maximum ambient temperature ta = 60°C, Temperature class B (130°C)

✔ Temperature switch 130°C integrated in primary winding - Automatically resetting, i.e. the transformer is not destroyed in the event of a short circuit!

✔ Toroidal transformer encapsulated on mounting plate with central through-hole - No further fastening material necessary

Technical specifications

Power:	200VA
Output voltage:	2x9V 18V
Output current:	2x11,12A
Input voltage:	2x115V
Frequency:	50/60Hz
Diameter:	118mm
Height:	58mm
Weight:	2,3kg
Open circuit voltage:	2x9,66V
No-load loss:	1,88VA
Max. Temperature:	60°C
Connection Entrance:	Strands, 200mm
Connection Entrance:	Strands, 200mm
Dielectric strength PRI-SEK:	4400V / 4,4kV
Temperature class:	B (130°C)
Thermoswitches:	130°C (automatically resetting)
Transformer grouted:	Yes
Efficiency:	92%
