Inrush current limiter MEAN WELL ICL-16L 16A 23A 180...264V AC
Available, delivery time 1-3 days
Article-No.:
IT-008178
Model:
ICL-16L
Shipping weight:
0.12 kg
Shipping Zone:
60
ROHS:
Ja
| Quantity | Unit price |
|---|---|
| 1 - 5 |
€24.70*
|
| 6 - 10 |
€24.45*
|
| 11 - 20 |
€24.21*
|
| 21 - 50 |
€23.96*
|
| 51 - 100 |
€23.96*
|
| From 101 |
€23.96*
|
Product description
| ✔ Inrush current limiter for Toroidal transformers Power supplies LED, etc. |
| ✔ Voltage: 180...264V AC |
| ✔ Rated current: 16A, max. 23A |
| ✔ Frequency: 47...63Hz |
| ✔ max. switching capacity: 3680VA (16A x 230V AC) |
| ✔ Ambient temperature: -30...+70°C |
| ✔ integrated Thermal fuse |
| ✔ Switching frequency: max. 2x per Second |
| ✔ Connections: Screw terminals 2,5mm² |
| ✔ Length: 90mm |
| ✔ Width: 35mm |
| ✔ Height: 54,5mm |
