Toroidal transformer 300VA 230V 2x30V 60V Lumonic RTO-826054
No longer available
Article-No.:
IT-005410
Model:
RTO-826054
Shipping weight:
2.8 kg
Shipping Zone:
80
ROHS:
Ja
Datasheet:
| Quantity | Unit price |
|---|---|
| 1 - 2 |
€72.00*
|
| 3 - 5 |
€71.28*
|
| 6 - 10 |
€70.56*
|
| 11 - 20 |
€69.84*
|
| 21 - 50 |
€69.84*
|
| From 51 |
€69.84*
|
Technical specifications
| Power: | 300VA |
|---|---|
| Output voltage: | 2x30V 60V |
| Output current: | 2x5,00A |
| Input voltage: | 230V |
| Frequency: | 50/60Hz |
| Diameter: | 127mm |
| Height: | 45mm |
| Weight: | 2,7kg |
| Open circuit voltage: | 2x32,50V |
| No-load loss: | 2,4VA |
| Max. Temperature: | 40°C |
| Connection Entrance: | Strands, 200mm |
| Connection Entrance: | Solid wires, 200mm |
| Dielectric strength PRI-SEK: | 4400V / 4,4kV |
| Temperature class: | B (130°C) |
| Transformer grouted: | No |
| Efficiency: | 91% |
