Toroidal transformer 120VA 230V 2x12V 24V Lumonic RSO-861756
Available, delivery time: 1-3 days
Article-No.:
IT-000248
Model:
RSO-861756
Shipping weight:
1.4 kg
Shipping Zone:
70
ROHS:
Ja
Datasheet:
| Quantity | Unit price |
|---|---|
| 1 - 5 |
€40.00*
|
| 6 - 10 |
€39.20*
|
| 11 - 20 |
€38.40*
|
| 21 - 50 |
€38.00*
|
| 51 - 100 |
€37.60*
|
| From 101 |
€37.20*
|
Technical specifications
| Power: | 120VA |
|---|---|
| Output voltage: | 2x12V 24V |
| Output current: | 2x5,00A |
| Input voltage: | 230V |
| Frequency: | 50/60Hz |
| Diameter: | 89mm |
| Height: | 48mm |
| Weight: | 1,5kg |
| Open circuit voltage: | 2x13,49V |
| Max. Temperature: | 40°C |
| Connection Entrance: | Solid wires, 200mm |
| Connection Entrance: | Solid wires, 200mm |
| Dielectric strength PRI-SEK: | 4400V / 4,4kV |
| Temperature class: | B (130°C) |
| Transformer grouted: | No |
