NSP-1600-36 1602W 36V 44,5A Industrial power supply
Available, delivery time: 1-3 days
Article-No.:
IT-009508
Model:
NSP-1600-36
Shipping weight:
1.8 kg
Shipping Zone:
70
ROHS:
Ja
Datasheet:
Product description
| ✔ universal AC input |
| ✔ built-in active PFC function |
| ✔ built-in ON/OFF remote control, remote sense, DC/OK signal, auxiliary power supply |
| ✔ Output voltage programmable |
| ✔ high efficiency of up to 92.5 |
| ✔ Protection functions: Short circuit / overload / overvoltage / overtemperature |
| ✔ 5 years warranty |
Technical specifications
| Power supply type: | Industrial power supply |
|---|---|
| Stabilisation: | Constant voltage |
| Topology: | AC/DC Converter |
| Input voltage: | 115V / 230V (Universal) |
| Output voltage: | 36V |
| Output current: | 44,5A |
| Power: | 1602W |
| Input voltage (min...max): | 90...264VAC |
| Output voltage (min...max): | 35,5…45VDC |
| Efficiency: | 91,5% |
| Input connection: | Screw terminals |
| Connection Output: | Screw terminals |
| Length: | 300mm |
| Width: | 85mm |
| Height: | 41mm |
