8-way junction box waterproof IP68, Fast, secure cable distribution, for cables 0.5-4mm², UV-resistant, -40°C to+ 105°C, Junction box for outdoor, garden, underground cable

Available, delivery time: 1-3 days

Article-No.: IT-010642

Shipping weight: 0.336 kg

Shipping Zone: 50

Ausführung

2-Wege

2-Wege gerade

3-Wege L

3-Wege Y

4-Wege

8-Wege

Quantity	Unit price
1 - 5	€8.50*
6 - 10	€8.33*
11 - 20	€8.16*
21 - 50	€8.08*
51 - 100	€7.99*
From 101	€7.91*

Prices incl. VAT plus shipping costs

VPE

aktueller
Bestand

Product description

✔ PERFECT SEALING: Eight flexible silicone seals in three sizes (4-8mm, 8-12mm, 10-14mm) adapt precisely to your cable and remain elastic even after years of use. No water penetrates, no RCD triggers. A seal is also installed between the housing and cover. Your garden lighting cabling and underground cables remain dry and safe for years.

✔ SPACIOUS INTERIOR: At 153x153x50mm, the 8-way box offers enough space for 8x cables from 0.5mm² to 4mm² (cable diameter 4-11mm) - including 8-way luster terminal. Cables are not crushed unnecessarily, clean wiring is easy. Saves time and nerves during installation.

✔ PREMIUM PC CASE: Impact-resistant polycarbonate housing with robust PA screw connections for a temperature range of -40°C to +105°C. CE, ENEC, UKCA, ETL, NSW, RoHS certified. Possible applications include PV systems, outdoor installations, extension of outdoor sockets, damp rooms and garden lighting. IP68 - 8m water depth for 150 hours.

✔ QUICK & EASY INSTALLATION: Select a suitable silicone seal, insert the cable, make the connections and tighten the cable glands (do not overtighten). Das Kabel muss fest und sicher sitzen. Bei der Montage des Deckels darauf achten, dass die Dichtung richtig sitzt und alle Schrauben mit dem auf dem Gehäuse aufgedruckten Drehmoment (0,5Nm) festgezogen werden.

✔ UV-RESISTANT & DURABLE: High-quality, black polycarbonate housing does not become brittle when exposed to sunlight. Complete set with three different sized silicone seals, 8-way luster terminal and stainless steel screws - ready for immediate use. Maximum load capacity up to 24A 450VAC.
