1m FLY Vehicle cable Black 25mm² round Cable Stranded wire CAR Power cable

Available, delivery time: 1-3 days

Article-No.: IT-007597000422

Shipping weight: 0.278 kg

Shipping Zone: 30

ROHS: Ja

Querschnitt

25mm²

Colour

Red

Black

aktueller
Bestand

Product description

✔ Conductor material: soft annealed electrolytic copper CU-ETP1 according to DIN EN 13602

✔ Conductor structure: according to DIN 72551 and ISO 6722-1

✔ Insulation: Soft PVC according to ISO6722-1, Class A - Shore A 90 ±2

✔ Flame retardancy: according to ISO 6722-1 / DIN EN 60332

✔ Waterproof + Oil and fuel resistant according to ISO 6722-1

✔ Bending radius: approx. 8x Cable diameter

✔ The order quantity will be delivered in one piece if possible.

Technical specifications

Cable type:	Vehicle cable
Cable specification:	FLY
Length:	1m
Cable cross section:	25mm²
Max. Operating voltage:	60V DC
Colour Cores:	Black
Diameter:	10,2mm
Material inner conductor:	Copper
Construction of inner conductor:	200x0,40mm
Temperature range:	-40...+85°C (3000h)
Insulation Cores:	PVC
